5.8.5 D5h Terminal Dimensions
130BF349.10
0.0
0.0
45 (1.8)
46 (1.8)
99 (3.9)
153 (6.0)
146 (5.8)
182 (7.2)
193 (7.6)
249 (9.8)
221 (8.7)
260 (10.2)
118 (4.6)
148 (5.8)
90 (3.6)
196 (7.7)
227 (9.0)
221 (8.7)
3
4
2
1
1 Mains terminals 3 Brake terminals
2 Ground terminals 4 Motor terminals
Illustration 5.15 D5h Terminal Dimensions with Disconnect Option (Front View)
Electrical Installation Operating Guide
MG21A502 Danfoss A/S © 09/2018 All rights reserved. 43
5 5
