5.8.6 D6h Terminal Dimensions
130BF353.10
0.0
96 (3.8)
195 (7.7)
227 (8.9)
123 (4.8)
153 (6.0)
458 (18.0)
0.0
46 (1.8)
50 (2.0)
99 (3.9)
147 (5.8)
182 (7.2)
193 (7.6)
221 (8.7)
249 (9.8)
260 (10.2)
146 (5.8)
1 Mains terminals 4 Brake terminals
2 Ground terminals 5 Motor terminals
3 TB6 terminal block for contactor – –
Illustration 5.19 D6h Terminal Dimensions with Contactor Option (Front View)
Electrical Installation Operating Guide
MG21A502 Danfoss A/S © 09/2018 All rights reserved. 47
5 5
