Danfoss VLT AQUA Drive FC 202 Operating Manual

5.8.7 D7h Terminal Dimensions
130BF359.10
0.0
0.0
2
1
372 (14.7)
412 (16.2)
395 (15.6)
515 (20.3)
66 (2.6) 95 (3.7)
131 (5.1) 151 (5.9) 195 (7.7) 238 (9.4)
292 (11.5) 346 (13.6)
49 (1.9)
198 (7.8)
368 (14.5)
545 (21.4)
3
4
1 Mains terminals 3 Motor terminals
2 Brake terminals 4 Ground terminals
Illustration 5.25 D7h Terminal Dimensions with Disconnect Option (Front View)
Electrical Installation Operating Guide
MG21A502 Danfoss A/S © 09/2018 All rights reserved. 53
5 5
