Danfoss VLT AQUA FC 202 Design Guide

Enclosure
A2
A3
A4
A5
NEMA
Chassis/Type 1
Chassis/Type 1
Type 12/4X
Type 12/4X
Table 7: Enclosures B1–B4: Power Sizes, Voltage Ranges, and Protection Rating
Enclosure
B1
B2
B3
B4
Power [kW]
200–240 V
5.5–11
15
5.5–11
15–18.5
380–480 V
11–18.5
22–30
11–18.5
22–37
525–600 V
11–18.5
22–30
11–18.5
22–37
525–690 V
–
11–30
–
11–37
e30ba812.11
e30ba813.11
e30ba826.11
e30ba827.11
IP
21/55/66
21/55/66
20/21
20/21
NEMA
Type 1/12/4X
Type 1/12/4X
Chassis
Chassis
Table 8: Enclosures C1–C4/D3h: Power Sizes, Voltage Ranges, and Protection Rating
Enclosure
C1
C2
C3
C4
D3h
(1)
Power [kW]
200–240 V
18.5–30
37–45
22–30
37–45
–
380–480 V
37–55
75–90
45–55
75–90
–
525–600 V
37–55
75–90
45–55
75–90
–
525–690 V
–
37–90
45–55
–
55–75
e30ba814.11
e30ba815.11
e30ba828.11
e30ba829.11
e30bu371.10
IP
21/55/66
21/55/66
20/21
20/21
20
NEMA
Type 1/12/4X
Type 1/12/4X
Chassis
Chassis
Chassis
1
Details, see separate design guide VLT AQUA Drive FC 202 110–800 kW
Standalone drives and enclosed drives
Based on the selected protection rating, select either a standalone drive or an enclosed drive.
AJ300847815559en-000101 / 130R033720 | Danfoss A/S © 2020.09
Product Family Overview
VLT® AQUA Drive FC 202
Design Guide
