FC 300 Design Guide
How to Program
Function:
Defines the Set-up number to control the
functions of the drive.
All parameters are programmed in four individual
parameter Set-ups, Set-up 1 - S et-up 4. Open
loop and closed-loop function can only be
changed with a stop signal applied. The Default
Set-up cannot be modified.
Default Set-up [0] contains the data set at Danfoss.
Can be used as a da ta source if the other Set-ups are
to be returned to a known state. Par. 0-50 and par.
0-06 allow copying from one Set-up to another or
to al l the other Set-ups. Set-ups 1-4 are individual
Set-ups, which can be selected individually.
Multi Set-up [9] is used by remote-selection
between Set-ups. U se digital inputs and the serial
communication por t for switchi ng between Set-ups.
Apply a stop signal when switching between Set-ups
where parameters marked as "not changeable
during operation" have different values. To make
sure that parameters marked as "not changeable
during operation" are never set differently in
two Set-ups, you should l ink the two Set-ups
together via par. 0-12. Parameters that are "not
changeable during operation" are m arked FALSE in
the parameter lists in the sec tion Parameter Lists
.
0-11 Edit Set-up
Option:
Factory setup [0]
*
Set-up 1 [1]
Set-up 2 [2]
Set-up 3 [3]
Set-up 4 [4]
Active Set-up [9]
Function:
Selects Editing Set-up. Editing is done via the
active Set-up or one of the inactive Se t-ups.
Selects the Set-up in which to program (change of
data) during operation (applies both via the control
panel and via the serial communication port). You
can program the 4 Set-ups independently of the
active Set-up (selected in par. 0-10 ).
Factory Set-up [0] contains default data and can be
used as a data source to return the other Set-ups
to a known state. Set-ups 1-4 are individual
Set-ups and can be used as required. They can be
programmed freely, regardless of the active S et-up.
0-12 This Set-up Link ed to
Option:
*
Set-up 1 [1]
Set-up 2 [2]
Set-up 3 [3]
Set-up 4 [4]
Function:
Apply a st op signal when switching between set-ups
where parameters marked as "not changeable
during operation" have different values. To make
sure that parameters marked a s "not change
able during operation" are never set differently
in two set-ups, link the two se t-ups together.
The adjustable freque n cy drive will autom atically
synchronize the parameter values. Parameters that
are not changeable during operation are marked
FALSE in the section Parameter Lists.
0-13 Readout: Linked Set-ups
Array [5]
Range:
0-255N/A
*
0N/A
Function:
A readout of all the set-ups linked together by
means of p ar. 0-12. The parameter has one index
for e ach parameter set-up. Each set-up shows the
set-up bi tset linked to that particular set-up.
Example where set-up 1 and 2 are linked:
Index LCP value
0{0}
1{1,2}
2{1,2}
3{3}
4{4}
0-14 Readout: Edit Set-ups / Channel
Range:
0 - FFF.FFF.FFF
*
AAA.AAA.AAA
*
default setting ()display text []value for use in communication via serial communication port
133
MG.33.B
3.22 - VLT is a registered Danfoss trademark
