Danfoss VLT AutomationDrive FC 300 Series Design Guide

FC 300 Design Guide
How to Program
Example - Reading a parameter value:
Requires a value in par. 3-4 1 Ramp 1 Up Time.
The ma ster sends the following request:
PKE = 1155 Hex - read par. 3-41 Ramp 1 Up Time
IND = 0000 Hex
PWE
HIGH
= 0 000 Hex
PWE
LOW
=0000Hex
If the value in par. 3-41 Ramp 1 Up Time is 10 s,
theresponsefromtheslavetothemasteris:
Conversion:
The various attributes of each parameter are
displayed in section Factory S ettings.Aparameter
value is only transferred as a whole number. Thus,
use a conversion factor to transfer decimals.
E
xample:
Par. 4-12 Motor Speed, Low Limit has a conversion
factor of 0.1. If you wish to preset the minimum
frequency to 10 Hz, transfer the value 100. A
conversion factor of 0.1 means that the value
transferred is multiplied by 0.1. The value
100 is thus perceived as 10.0.
Conversion table
Conversion index Conversion factor
74 0.1
2 100
110
01
-1 0.1
-2 0. 01
-3 0.001
-4 0.0001
-5 0.00001
" Process Words
The block of process words is divided into
two blocks of 16 bits, w
hich always occur
in the defined sequence.
PCD 1 PCD 2
Control t
elegram (master=>slave)
Control w
ord
Referenc
evalue
Control t
elegram (slave=>master)
Status wo
rd
Present o
utp. frequency
*
default setting ()display text []value for use in communication via serial c ommunication port
242
MG.33.B
3.22 - VLT is a registered Danfoss trademark
