Danfoss VLT AutomationDrive FC 300 Series Design Guide

FC 300 Design Guide
How to Program
" Parameters: Operation
and Display
" 0-0* Basic Settings
0-01 Language
Option:
*
English UK (ENGLISH) [0]
German (DEUTSCH) [1]
French (FRANCAIS) [2]
Danish (DANSK) [3]
Spanish (ESPANOL) [4]
Italian (ITALIANO) [5]
Chinese (CHINESE) [10]
Finnish (FINNISH) [20]
English US (ENGLISH US) [22]
Greek (GREEK) [27]
Portuguese (PORTUGUESE) [28]
Slovenian (SLOVENIAN) [36]
Korean (KOREAN) [39]
Japanese (JAPANESE) [40]
Turkish (TURKISH) [41]
Traditional Chinese [42]
Bulgarian [43]
Serbian [44]
Romanian (ROMANIAN) [45]
Hungarian (HUNGARIAN) [46]
Czech [47]
Polish (POLISH) [48]
Russian [49]
Thai [50]
Bahasa Indonesian (BAHASA
INDONESIAN) [51]
Function:
Defines the language to be used in display.
The adjustable frequency drive can be delivered
with 4 various language packages. English and
German are inc luded in all packages. E ng lish
cannot be erased or manipulated.
0-02 Motor Spe ed Unit
Option:
*
RPM [0]
Hz [1]
Function:
Defines the parameters for motor speed (i.e.
references, feedb
acks, limits) displayed in t erms
of shaft speed (in RPM) or the output frequency
to the motor (Hz). This parameter cannot be
adjusted while the motor is running.
0-03 Regional Settings
Option:
*
International [0]
US [1]
Function:
Select International [0] to set the unit of par.1-20
Motor Power in kW and the default setting of par.
1-23 to 50 Hz. Select "[1] US" to set the unit
of par. 1-21 Motor Power in HP and the default
value of par. 1-23 to 60 Hz. Par. 0-03 cannot
be adjusted w hile the motor is running.
0-04 Operating State at Power-up (Hand)
Option:
Resume [0]
*
Forced stop, use saved reference [1]
Forced stop, reference = 0 [2]
Function:
Sets the operating mode when mains voltage
is reconnected after p ower down in Hand
(local) operation.
Select Resume [0] to start up the drive with the
same local reference and the same start/stop
conditions (applie d b y [START/STOP]) as before
the drive was switched off.
Use Forced stop, use saved reference [1] to
stop the drive until mains voltage reappears
and until you press [START]. After the start
command, set the local refere nce.
Select Forced stop , set reference to 0 [2] to
stop the drive until mains voltage reappears.
Local reference is reset.
" 0-1* Set-Up Handling
0-10 Active Set-up
Option:
Factory setup [0]
*
Set-up 1 [1]
Set-up 2 [2]
Set-up 3 [3]
Set-up 4 [4]
Multi set-up [9]
*
default setting ()display text []value for use in communication via serial communication port
132
MG.33.B
3.22 - VLT is a registered Danfoss trademark
