FC 300 Design Guide
How to Program
" Parameters: Drive
Information
" 15-0* Operating Data
15-00 Operating Hours
Range:
0 - 2147 483647 h
*
0h
Function:
Indicates how long the adjus table frequency
drive has run. The value is saved when
the unit is turned off.
15-01 Running Hours
Range:
0 - 2147 483647 h
*
0h
Function:
Indicates how many hours the motor has run.
Reset counter in par. 15-07. The value is
saved w hen the unit is turned off.
15-02 kWh Counter
Range:
0 - 2147483647 kWh
*
0kWh
Function:
States the p ower consumption from mains in
kWh as a mean value over one hour. Reset
counter: Par. 15-06.
15-03 Power-ups
Range:
0 - 2147483647
*
0
Function:
States the number of power-ups to the
adjustable frequency drive.
15-04 Ove r Temps
Range:
0 - 65535
*
0
Function:
States the numb er of temperature faults on
the adjusta ble frequency drive.
15-05 Over Volts
Range:
0 - 65535
*
0
Function:
States the number of overvoltages on the
adjustable frequency drive.
15-06 Reset kWh Counter
Option:
*Do no t reset [0]
Reset counter [1]
Function:
Reset to zero of kWh hour counter (par. 15-02).
Reset the kWh counter by selecting Reset [1 ] and
pressing [OK]. It is not possible to select this
parameter via the serial port, RS-485.
NOTE
The reset is carried out by pressing [OK].
15-07 Reset Running Hours Counter
Option:
*
Do not reset [0]
Reset counter [1]
Function:
Resets the running hours counter to
zero (par. 15-01).
Reset the running hours counter by selecting Reset
[1] and pressing [OK]. It is not possible to s elect
this parameter via the serial p ort, RS-485.
" 15-1* Data Log Settings
The Data Log enables continuous logging of up
to 4 data sources (par. 15-10) at individual
rates (par. 15-11). A trigger event (par. 15-12)
and window (par. 15-14) are used to s tart and
stop the logg ing conditionally.
15-10 Logging Source
Array [4]
Option:
None
16-00 Control Word
16-01 Reference [Unit]
16-02 Reference %
16-03 S tatus Word
16-10 Power [kW]
16-11 Power [hp]
16-12 Mo tor voltage
*
default setting ()display text []value for use in communication via serial communication port
209
MG.33.B
