Danfoss VLT AutomationDrive FC 300 Series Design Guide

FC 300 Design Guide
How to Program
16-13 Frequency
16-14 Motor Current
16-16 Torque
16-17 Speed [RP M]
16-18 Motor Thermal
16-30 DC Link Voltage
16-32 Brake Ene rgy /s
16-33 Brake Energy / 2 min
16-34 Heatsink Temp.
16-35 Inverter Thermal
16-50 External Reference
16-51 Pulse Reference
16-52 Feedback [Unit]
16-60 Digital Input
16-62 Analog Input 53
16-64 Analog Input 54
16-65 Analog Output 42 [mA]
16-66 Digital Output [bin]
16-90 Alarm Word
16-92 Warning Word
16-94 Ext. Sta tus Word
Function:
This parameter selects whic h variable is logg ed.
15-11 Logging Interval
Range:
1 - 8 6400000 m s
*
1ms
Function:
Select the interval in milliseconds between
each sampling of the variable.
15-12 Trigger Event
Option:
FALSE [0]
TRUE [1]
Running [2]
In range [3]
On reference [4]
To rque lim it [5]
Current limit [6]
Out of current range [7]
Below I low [8]
Above I high [9]
Out of speed range [10]
Below speed low [11]
Above speed high [12]
Out of feedb. range [13]
Below feedb. low [14]
Above feedb. high [15]
Thermal warning [16]
Mains out of range [17]
Reverse [18]
Warning [19]
Alarm (trip) [20]
Alarm (trip lock) [21 ]
Comparator 0 [22]
Comparator 1 [23]
Comparator 2 [24]
Comparator 3 [25]
Logic rule 0 [26 ]
Logic rule 1 [27 ]
Logic rule 2 [28 ]
Logic rule 3 [29 ]
Digital input DI18 [33]
Digital input DI19 [34]
Digital input DI27 [35]
Digital input DI29 [36]
Digital input DI32 [37]
Digital input DI33 [38]
Function:
Select the trigger event. If the event occurs,
a window is applied to freeze the log. Af ter
that, it contains a specified number of sam ple s
before and after the oc currence of the trigger
event (par. 15-14).
15-13 Logging Mode
Option:
*
Log always [0]
Log once on trig ger [1]
Function:
Select if the logging is continuous (Log always)
or conditionally started and stopped (Log once
on trigger) (par. 15-12 and 15-1
4).
15-14 Samples Before Trigger
Range:
0-100N/A
*
50N/A
Function:
Specify the percentage of all samples that are
logged before the trigger event.
" 15-2* Historic Log
It is possible to view up to 50
data logs, via
these array p arameters. [0] is the latest log and
*
default setting ()display text []value for use in communication via serial communication port
210
MG.33.B
3.22 - VLT is a registered Danfoss trademark
