FC 300 Design Guide
Introduction to FC 300
" Required Compliance Levels
Standard / environment Housing, trades, and light industries Industrial environment
Conducted Radiated Conducted Radiated
IEC 61000-6-3 Class B Class B
IEC 61000-6-4 Class A-1 Class A-1
EN 61800-3 (restricted)
Class B Class B Class A-2 Class A-2
EN 61800-3 (unrestricted) Class A-1 Class A-1 Class A-2 Class A-2
EN 55011: Threshold values and measuring methods for radio interference from industrial, s cientific and
medical (ISM) high-frequency equipm ent.
Class A-1: Equipment used in an indus trial environme nt.
Class A-2: Equipment used in an indus trial environme nt.
Class B-1: Equipment u sed in areas with a public supply network (dwellings, commerce, and light industries).
"
EMC Immunity
In order to document i mmunity against electrical interference from electrical p henomena, the following
immunity tests have been carried out on a system consisting of an adjustable frequency drive (with options,
if relevant), a shielded control cab le, and a control box with potentiometer, mo tor cable, and m o tor.
The tests w ere per formed in accordance with the following basic standards:
• EN 61000-4-2 (IEC 61000-4-2): Electrostatic discharges (ESD)
Simulation of electrostatic discharges from human beings.
• EN 610 00 - 4-3 (IEC 61 000-4-3): Incoming electromagnetic field radiation, am plitude modulated
Simulation of the effec ts of radar and radio communication equipment as well as mobile communications.
• EN 61000-4-4 (IEC 61000-4-4): Transients
Simulation of interference broug h t about by switching with a contactor, relays, or similar devic es.
• EN 61000-4-5 (IEC 61000-4-5): Surge transients
Simulation of transients brought about e.g. by lightning that strikes near installations.
• EN 61000-4-6 ( IEC 61000-4-6): RF Common mode
Simulation of the effect from radio-transmitting equipment connected to connectio n cables.
See following EMC immunity form.
46
MG.33.B3.22 - VLT is a registered Danfoss trademark
