Danfoss VLT AutomationDrive FC 300 Series Design Guide

FC 300 Design Guide
How to Program
Function:
Choose between controlling the drive via the
terminals (digital input) and/or via the bus.
Select Bus, a Start command ca n only be activated
if it is transmitted via the serial communication
port or fieldbus option. If Logic AND is select ed,
a comm and via one of the digital inputs must be
activated. Selecting Logic OR, a Start command via
one of the digital inputs must be activated.
NOTE
This parameter is a ct ive only when
par. 8-01 Control Site is set to [0]
Digital and control word.
8-54 Reverse Select
Option:
Digital input [0]
Bus [1]
Logic AND [2]
*
Logic OR [3]
Function:
Choose between controlling the drive via the
terminals (digital input) and/or via the bus.
Select Bus, a Reversing c ommand can only
be activated if it is transmitted via the serial
communication port or fieldbus option. If Logic
AND is selected, a command via o ne of the
digital inputs must be activated. Selecting
Logic OR, a Reversing command via one of the
digital inputs must be activated.
NOTE
This parameter is a ct ive only when
par. 8-01 Control Site is set to [0]
Digital and control word.
8-55 Set-up Select
Option:
Digital input [0]
Bus [1]
Logic AND [2]
*
Logic OR [3]
Function:
Choose between controlling the drive via the
terminals (digital input
) and/or via the bus.
Select Bus, a Selection of Setup can only b e activated
if it is transmitted via the serial communication
port or fieldbus option.
If Logic AND is selected,
a command via one of the digital inputs must be
activated. Selecting Logic OR, a Set-up command
via one of the digital inputs must be activated.
NOTE
This parameter is active only when
par. 8-01 Control Site is set to [0]
Digital and control word.
8-56 Preset Reference Select
Option:
Digital input [0]
Bus [1]
Logic AND [2]
*
Logic OR [3]
Function:
Choose between controlling the drive via the
terminals (digital input) and/or via the bus.
Select Bus,a Preset Reference command can
only be activate if it is transmitted via the serial
communication port or fieldbus option. If Logic
AND is selected, a command via one of the
digital inputs must be activated. Selecting Logic
OR, a Preset Reference command via one of the
digital inputs must be activated.
NOTE
This parameter is active only when
par. 8-01 Control Site is set to [0]
Digital and control word.
" 8-9* Bus Jog
8-90 Bus Jog 1 Speed
Range:
0-par. 4-13RPM
*
100RPM
Function:
Sets a fixed speed (jog) activated via the
serial port or bus o ption.
8-91 Bus Jog 2 Speed
Range:
0-par. 4-13RPM
*
200RPM
Function:
Sets a fixed speed (jog) activated via the
serial port or bus option
*
default setting ()display text []value for use in communication via serial communication port
185
MG.33.B
3.22 - VLT is a registered Danfoss trademark
