Page #193 background image
FC 300 Design Guide
How to Program
Control Word par. 16-00
Reference [Unit] par. 16-01
Reference % par. 16-02
Status Word par. 16-03
Power [kW] par. 16-10
Power [hp] par. 16-11
Motor Voltage par. 1 6-12
Frequency par. 16-13
Motor Current par. 16-14
Torque pa r. 16-16
Speed [RPM] par. 16-17
Motor thermal par. 16-18
KTY sensor tempe rature par. 16-19
Phase angle par. 16-20
DC Link Voltage par. 16-30
BrakeEnergy/s par. 16-30
BrakeEnergy/2 min par. 16-33
Heatsinktemp.par.16-34
Inverter thermal par. 16-35
SL Controller State pa r. 1 6-38
Controlcard temp. p ar. 16-39
External Reference par. 16-50
Pulse Reference par. 16 -51
Feedback [Unit] pa r. 16-52
External Reference par. 16-53
Terminal 53 Switch Setting par. 16-63
Analog Input 53 par. 16-62
Terminal 54 Switch Setting par. 16-63
Analog Input 54 par. 16-64
AnalogOutput42[mA]par. 16-65
Digital Output [bin] par. 16-66
Freq. input #29 [Hz] par. 1 6-67
Freq. input #33 [Hz] par. 1 6-68
Pulse output #27 [Hz] par. 16-6
9
Pulse output #29 [Hz] par. 16-70
Comm Option STW par. 16-84
FC port CTW 1 par. 16-85
Alarm Word par. 16-90
Alarm Word 2 par. 16-91
WarningWordpar. 16-
92
WarningWord2par. 16-93
Extended Status Word par. 16-94
Extended Status
Word 2 par. 16-95
Function:
Used for the pre-defined I/O assembly Instances.
Only 2 elem ents
[1,2] of this array are used. All
elements are set to 0 as default.
10-13 Warning Parameter
Range:
0-63
*
63
Function:
Reads out warning messages via standard bus or
DeviceNet. This parameter is not available via LCP
but you can see the warning message by choosing
Com warning word as display readout. One bit is
assigned to every warning (see manual for list).
Bit: Meaning:
0 Bus not active
1 Explicit conne ction timeout
2 I/O connection
3 Retry limit reached
4 Actual is not updated
5CANbusoff
6 I/O send error
7 Initialization error
8Nobussupply
9 Bus off
10 Error passive
11 Error warning
12 Duplicate MAC ID Error
13 RX queue overrun
14 TX queue overrun
15 CAN overrun
10-14 Net Reference
Option:
Read-only from LCP.
*
Off [0]
On [1]
Function:
Enables selection of reference source in
Instance 21/71 and 20/70.
- Off: Enables reference via analog/digital inputs.
- On: Enables reference via the bus.
10-15 Net Control
Option:
Read-only from LCP.
*
Off [0]
On [1]
*
default setting ()display text []value for use in communication via serial communication port
193
MG.33.B
3.22 - VLT is a registered Danfoss trademark
