Danfoss VLT FC 103 Instruction Manual

Area Title Functions
8 Control circuitry
•
Input power, internal
processing, output, and motor
current are monitored to
provide efficient operation
and control
•
User interface and external
commands are monitored and
performed
•
Status output and control can
be provided
Table 1.3 Legend to Figure 1.3
1.4 Frame Sizes and Power Ratings
Frame Size (hp [kW])
[V] A2 A3 A4 A5 B1 B2 B3 B4 C1 C2 C3 C4
200–240 1.5–3
[1.1–
2.2]
4–5
[3.0–3.7]
1.5–3
[1.1–2.2]
1.5–5
[1.1–3.7]
7.5–15
[5.5–11]
20 [15] 7.5–15
[5.5–11]
20–25
[15–18.5]
25–40
[18.5–30]
50–60
[37–45]
30–40
[22–30]
50–60
[37–45]
380–480 1.5–5
[1.1–
4.0]
7.5–10
[5.5–7.5]
1.5–5
[1.1–4.0]
1.5–10
[1.1–7.5]
15–25
[11–18.5]
30–40
[22–30]
15–25
[11–18.5]
30–50
[22–37]
50–75
[37–55]
100–125
[75–90]
60–75
[45–55]
100–125
[75–90]
525–600 N/A 1.5–10
[1.1–7.5]
N/A 1.5–10
[1.1–7.5]
15–25
[11–18.5]
30–40
[22–30]
15–25
[11–18.5]
30–50
[22–37]
50–75
[37–55]
100–125
[75–90]
60–75
[45–55]
100–125
[75–90]
Table 1.4 Frame Sizes and Power Ratings
Introduction Instruction Manual
MG16E222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 7
1 1
