3.4 Asynchronous Motor Set-up
Enter the motor data in parameters 1-20/1-21 to 1-25. The
information can be found on the motor nameplate.
1.
1-20 Motor Power [kW] or 1-21 Motor
Power [HP]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
130BT772.10
Q2
0.0 Hz 0.00kW 1(1)
Motor Setup
1 - 21 Motor Power [kW]
4.0 kW
Figure 3.30 Motor Set-up
3.5 Automatic Motor Adaptation
Automatic motor adaptation (AMA) is a test procedure that
measures the electrical characteristics of the motor to
optimize compatibility between the adjustable frequency
drive and the motor.
•
The adjustable frequency drive builds a
mathematical model of the motor for regulating
output motor current. The procedure also tests
the input phase balance of electrical power. It
compares the motor characteristics with the data
entered in parameters 1-20 to 1-25.
•
The motor shaft does not turn and no harm is
done to the motor while running the AMA.
•
Some motors may be unable to run the complete
version of the test. In that case, select [2] Enable
reduced AMA.
•
If an output filter is connected to the motor,
select Enable reduced AMA.
•
If warnings or alarms occur, see
chapter 8 Warnings and Alarms.
•
Run this procedure on a cold motor for best
results.
NOTICE!
The AMA algorithm does not work when using PM
motors.
To run AMA
1. Press [Main Menu] to access parameters.
2.
Scroll to parameter group 1-** Load and Motor.
3. Press [OK].
4.
Scroll to parameter group 1-2* Motor Data.
5. Press [OK].
6.
Scroll to 1-29 Automatic Motor Adaptation (AMA).
7. Press [OK].
8.
Select [1] Enable complete AMA.
9. Press [OK].
10. Follow the on-screen instructions.
11. The test will run automatically and indicate when
it is complete.
3.6
PM Motor Set-up in VVC
plus
CAUTION
Use only a PM motor with fans and pumps.
Initial Programming Steps
1.
Activate PM motor operation 1-10 Motor
Construction, select [1) PM, non-salient SPM
2.
Make sure to set 0-02 Motor Speed Unit to [0] RPM
Programming motor data
After selecting PM motor in 1-10 Motor Construction, the
PM motor-related parameters in parameter groups 1-2*
Motor Data, 1-3* Adv. Motor Data and 1-4* are active.
The information can be found on the motor nameplate
and in the motor data sheet.
The following parameters must be programmed in the
listed order:
1.
1-24 Motor Current.
2.
1-26 Motor Cont. Rated Torque.
3.
1-25 Motor Nominal Speed.
4.
1-39 Motor Poles.
5.
1-30 Stator Resistance (Rs).
Enter line to common stator winding resistance
(Rs). If only line-line data are available, divide the
line-line value by 2 to achieve the line to
common (starpoint) value.
Start-up and Functional Tes...
Instruction Manual
38 Danfoss A/S © Rev. 2014-02-10 All rights reserved. MG16E222
