Danfoss VLT FC 103 Instruction Manual

4. Mount line power plug and tighten wires
130BA263.10
95
M
A
INS
+DC
BR-
BR+
U
V
W
91
92
93
L1
L2
L3
RELAY 1 RELAY 2
Figure 2.22 Line Power Plug Mounting
5. Tighten support bracket on line power wires
+DC
BR-
BR+
U
V
W
MAINS
L1 L2 L3
91 92 93
RELAY 1 RELAY 2
99
- LC -
130BA264.10
Figure 2.23 Support Bracket Mounting
2.4.5.2
AC Line Input Connection for A4
and A5
NOTICE!
A cable clamp is used.
L 1
L 2
L 3
91
92
93
130BT336.10
Figure 2.24 Connection to Line Power and Grounding without
Line Power Disconnect Switch
130BT335.10
Figure 2.25 Connection to Line Power and Grounding with
Line Power Disconnect Switch
Installation Instruction Manual
MG16E222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 21
2 2
