Danfoss VLT FC 103 Instruction Manual

10 Specifications
10.1 Power-dependent Specifications
10.1.1 Line power supply 3x200–240 V AC
Adjustable frequency drive
Typical Shaft Output [kW]
P1K1
1.1
P1K5
1.5
P2K2
2.2
P3K0
3
P3K7
3.7
IP20/Chassis
6)
A2 A2 A2 A3 A3
IP55/Type 12 A4/A5 A4/A5 A4/A5 A5 A5
IP66/NEMA 4X A4/A5 A4/A5 A4/A5 A5 A5
Typical Shaft Output [HP] at 208 V 1.5 2.0 2.9 4.0 4.9
Output current
Continuous
(3x200–240 V) [A]
6.6 7.5 10.6 12.5 16.7
Intermittent
(3x200–240 V) [A]
7.3 8.3 11.7 13.8 18.4
Continuous
kVA (208 V AC) [kVA]
2.38 2.70 3.82 4.50 6.00
Max. input current
Continuous
(3x200–240 V) [A]
5.9 6.8 9.5 11.3 15.0
Intermittent
(3x200–240 V) [A]
6.5 7.5 10.5 12.4 16.5
Additional specifications
Estimated power loss
at rated max. load [W]
4)
63 82 116 155 185
IP20, IP21 max. cable cross-section (line power, motor,
brake and load sharing) [mm
2
/(AWG)]
4, 4, 4 (12, 12, 12)
(min. 0.2 (24))
IP55, IP66 max. cable cross-section (line power, motor,
brake and load sharing) [mm
2
/(AWG)]
4, 4, 4 (12, 12, 12)
Max. cable cross-section with disconnect 6, 4, 4 (10, 12, 12)
Weight enclosure IP20 (lb [kg]) 10.8 [4.9] 10.8 [4.9] 10.8 [4.9] 14.55 [6.6] 14.55 [6.6]
Weight enclosure IP21 (lb [kg]) 12.13 [5.5] 12.13 [5.5] 12.13 [5.5] 16.54 [7.5] 16.54 [7.5]
Weight enclosure IP55 (lbs [kg]) (A4/A5) 21.39/29.76
[9.7/13.5]
21.39/29.76
[9.7/13.5]
21.39/29.76
[9.7/13.5]
29.76 [13.5] 29.76 [13.5]
Weight enclosure IP66 (lbs [kg]) (A4/A5) 21.39/29.76
[9.7/13.5]
21.39/29.76
[9.7/13.5]
21.39/29.76
[9.7/13.5]
29.76 [13.5] 29.76 [13.5]
Efficiency
3)
0.96 0.96 0.96 0.96 0.96
Table 10.1 Line Power Supply 3x200–240 V AC - Normal overload 110% for 1 minute
Specifications Instruction Manual
76 Danfoss A/S © Rev. 2014-02-10 All rights reserved. MG16E222
1010
