Start
L
1
L
2
PE
F1
gL/UR
91 92 93
FC 103
12
18
54
55
Cables type: LIYCY
Ltot. max. = 40 mm
Alarm
Motor
U V W PE
96 97 95 93
Motors insulation class B minimum
130BA760.11
Figure 6.3 Pressure Control in Closed-loop – Stand Alone System – Single Fan or Pump/Multiple Fans or Pumps in Parallel
6.2.3
Compressor Pack
Figure 6.4 P
0
Pressure Transmitter
FC 103
Supply
1 2
AKS33
12 18 27 20 55 54 U V W
130BA808.11
Figure 6.5 How to Connect the FC 103 and AKS33 for Closed-
loop Applications
NOTICE!
To find out which parameters are relevant, run the wizard.
Application Set-up Examples Instruction Manual
MG16E222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 59
6 6
