Danfoss VLT FC 103 Instruction Manual

10.1.4 Line Power Supply 3 x 525–690 V AC
Adjustable frequency drive
Typical Shaft Output [kW]
P11K
11
P15K
15
P18K
18.5
P22K
22
P30K
30
P37K
37
P45K
45
P55K
55
P75K
75
P90K
90
Typical Shaft Output [HP] at
575 V
10 16.4 20.1 24 33 40 50 60 75 100
IP21/NEMA 1 B2 B2 B2 B2 B2 C2 C2 C2 C2 C2
IP55/NEMA 12 B2 B2 B2 B2 B2 C2 C2 C2 C2 C2
Output current
Continuous
(3x525–550 V) [A]
14 19 23 28 36 43 54 65 87 105
Intermittent
(3x525–550 V) [A]
15.4 20.9 25.3 30.8 39.6 47.3 59.4 71.5 95.7 115.5
Continuous
(3x551–690 V) [A]
13 18 22 27 34 41 52 62 83 100
Intermittent
(3x551–690 V) [A]
14.3 19.8 24.2 29.7 37.4 45.1 57.2 68.2 91.3 110
Continuous kVA
(550 V AC) [kVA]
13.3 18.1 21.9 26.7 34.3 41 51.4 61.9 82.9 100
Continuous kVA
(575 V AC) [kVA]
12.9 17.9 21.9 26.9 33.8 40.8 51.8 61.7 82.7 99.6
Continuous kVA
(690 V AC) [kVA]
15.5 21.5 26.3 32.3 40.6 49 62.1 74.1 99.2 119.5
Max. cable size
(line power, motor, brake)
[mm
2
]/(AWG)]
2)
35 (1/0) 95 (4/0)
Max. input current
Continuous
(3x525–690 V) [A]
15 19.5 24 29 36 49 59 71 87 99
Intermittent
(3x525–690 V) [A]
16.5 21.5 26.4 31.9 39.6 53.9 64.9 78.1 95.7 108.9
Max. pre-fuses
1)
[A]
63 63 63 63 80 100 125 160 160 160
Environment:
Estimated power loss
at rated max. load [W]
4)
201 285 335 375 430 592 720 880 1200 1440
Weight:
IP21 (lbs [kg])
59.53
[27]
59.53
[27]
59.53
[27]
59.53
[27]
59.53
[27]
143.3
[65]
143.3
[65]
143.3 [65]
143.3
[65]
143.3
[65]
IP55 (lb [kg])
59.53
[27]
59.53
[27]
59.53
[27]
59.53
[27]
59.53
[27]
143.3
[65]
143.3
[65]
143.3 [65]
143.3
[65]
143.3
[65]
Efficiency
4)
0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98
Specifications Instruction Manual
MG16E222 Danfoss A/S © Rev. 2014-02-10 All rights reserved. 83
