Danfoss VLT FC 103 Instruction Manual

Enclosure size Power (hp [kW]) Recommended fuse size Recommended max. fuse
Recommended circuit
breaker Danfoss
Max. trip level
[A]
A3
1.5 [1.1] gG-6 gG-25 CTI25M 10-16 16
2 [1.5] gG-6 gG-25 CTI25M 10-16 16
3 [2.2] gG-6 gG-25 CTI25M 10-16 16
4 [3] gG-10 gG-25 CTI25M 10-16 16
5 [4] gG-10 gG-25 CTI25M 10-16 16
7.5 [5.5] gG-16 gG-25 CTI25M 10-16 16
10 [7.5] gG-16 gG-25 CTI25M 10-16 16
B2
15 [11] gG-25 gG-63
20 [15] gG-25 gG-63
25 [18] gG-32
30 [22] gG-32
C2
40 [30] gG-40
50 [37] gG-63 gG-80
60 [45] gG-63 gG-100
75 [55] gG-80 gG-125
100 [75] gG-100 gG-160
C3
50 [37] gG-100 gG-125
60 [45] gG-125 gG-160
D
50 [37] gG-125 gG-125
60 [45] gG-160 gG-160
75–100 [55–75] gG-200 gG-200
125 [90] aR-250 aR-250
150 [110] aR-315 aR-315
175–250
[132–160] aR-350 aR-350
300 [200] aR-400 aR-400
350 [250] aR-500 aR-500
450 [315] aR-550 aR-550
E
475–550
[355–400] aR-700 aR-700
650–750 [500–
560] aR-900 aR-900
F
850–1200
[630–900] aR-1600 aR-1600
1350 [1000] aR-2000 aR-2000
1600 [1200] aR-2500 aR-2500
Table 10.10 525–690 V, Frame Sizes A, C, D, E and F (non-UL fuses)
Specifications Instruction Manual
92 Danfoss A/S © Rev. 2014-02-10 All rights reserved. MG16E222
