Danfoss VLT HVAC

Size/Type Bussmann PN* Rating Ferraz Siba
P450 170M4017 700 A, 700 V 6.9URD31D08A0700 20 610 32.700
P500 170M4017 700 A, 700 V 6.9URD31D08A0700 20 610 32.700
P560 170M6013 900 A, 700 V 6.9URD33D08A0900 20 630 32.900
P630 170M6013 900 A, 700 V 6.9URD33D08A0900 20 630 32.900
Table 5.13: Frame size E, 525-690 V
Size/Type
Bussmann PN* Rating Siba Internal Bussmann Option
P710 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
P800 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
P900 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
P1M0 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
P1M2 170M7082 2000 A, 700 V 20 695 32.2000 170M7082
P1M4 170M7083 2500 A, 700 V 20 695 32.2500 170M7083
Table 5.14: Frame size F, Line fuses, 525-690 V
Size/Type
Bussmann PN* Rating Siba
P710 170M8611 1100 A, 1000 V 20 781 32. 1000
P800 170M8611 1100 A, 1000 V 20 781 32. 1000
P900 170M8611 1100 A, 1000 V 20 781 32. 1000
P1M0 170M8611 1100 A, 1000 V 20 781 32. 1000
P1M2 170M8611 1100 A, 1000 V 20 781 32. 1000
P1M4 170M8611 1100 A, 1000 V 20 781 32.1000
Table 5.15: Frame size F, Inverter module DC Link Fuses, 525-690 V
*170M fuses from Bussmann shown use the -/80 visual indicator, -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and amperage
may be substituted for external use.
Suitable for use on a circuit capable of delivering not more than 100 000 rms symmetrical amperes, 500/600/690 Volts maximum when protected by the
above fuses.
Supplementary fuses
Frame size Bussmann PN* Rating
D, E and F KTK-4 4 A, 600 V
Table 5.16: SMPS Fuse
Size/Type
Bussmann PN* LittelFuse Rating
P110-P315, 380-480 V KTK-4 4 A, 600 V
P45K-P500, 525-690 V KTK-4 4 A, 600 V
P355-P1M0, 380-480 V KLK-15 15A, 600 V
P560-P1M4, 525-690 V KLK-15 15A, 600 V
Table 5.17: Fan Fuses
Size/Type
Bussmann PN* Rating Alternative Fuses
P500-P1M0, 380-480 V 2.5-4.0 A LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 6A
P710-P1M4, 525-690 V LPJ-10 SP or SPI 10 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 10 A
P500-P1M0, 380-480 V 4.0-6.3 A LPJ-10 SP or SPI 10 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 10 A
P710-P1M4, 525-690 V LPJ-15 SP or SPI 15 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 15 A
P500-P1M0, 380-480 V 6.3 - 10 A LPJ-15 SP or SPI 15 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 15 A
P710-P1M4, 525-690 V LPJ-20 SP or SPI 20 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 20A
P500-P1M0, 380-480 V 10 - 16 A LPJ-25 SP or SPI 25 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 25 A
P710-P1M4, 525-690 V LPJ-20 SP or SPI 20 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 20 A
Table 5.18: Manual Motor Controller Fuses
