Danfoss VLT HVAC

4.1.3 Type Code String High Power
Ordering type code frame sizes D and E
Description Pos Possible choice
Product group+series 1-6 FC 102
Power rating 8-10 45-560 kW
Phases 11 Three phases (T)
Mains voltage 11-
12
T 4: 380-500 VAC
T 7: 525-690 VAC
Enclosure 13-
15
E00: IP00/Chassis
C00: IP00/Chassis w/ stainless steel back channel
E0D: IP00/Chassis, D3 P37K-P75K, T7
C0D: IP00/Chassis w/ stainless steel back channel, D3 P37K-P75K, T7
E21: IP 21/ NEMA Type 1
E54: IP 54/ NEMA Type 12
E2D: IP 21/ NEMA Type 1, D1 P37K-P75K, T7
E5D: IP 54/ NEMA Type 12, D1 P37K-P75K, T7
E2M: IP 21/ NEMA Type 1 with mains shield
E5M: IP 54/ NEMA Type 12 with mains shield
RFI filter 16-
17
H2: RFI filter, class A2 (standard)
H4: RFI filter class A1
1)
H6: RFI filter Maritime use
2)
Brake 18 B: Brake IGBT mounted
X: No brake IGBT
R: Regeneration terminals (E frames only)
Display 19 G: Graphical Local Control Panel LCP
N: Numerical Local Control Panel (LCP)
X: No Local Control Panel (D frames IP00 and IP 21 only)
Coating PCB 20 C: Coated PCB
X. No coated PCB (D frames 380-480/500 V only)
Mains option 21 X: No mains option
3: Mains disconnect and Fuse
5: Mains disconnect, Fuse and Load sharing
7: Fuse
A: Fuse and Load sharing
D: Load sharing
Adaptation 22 Reserved
Adaptation 23 Reserved
Software release 24-
27
Actual software
Software language 28
A options 29-30 AX: No options
A0: MCA 101 Profibus DP V1
A4: MCA 104 DeviceNet
B options 31-32 BX: No option
BK: MCB 101 General purpose I/O option
BP: MCB 105 Relay option
BO: MCB 109 Analog I/O option
C
0
options 33-34 CX: No options
C
1
options 35 X: No options
C option software 36-37 XX: Standard software
D options 38-39 DX: No option
D0: DC backup
The various options are described further in this Design Guide.
1): Available for all D frames. E frames 380-480/500 VAC only
2) Consult factory for applications requiring maritime certification
