4.2.2 Ordering Numbers: High Power Option Kits
Kit Description Ordering Number Instruction Number
NEMA-3R (Rittal Enclosures) D3 Frame 176F4600 175R5922
D4 Frame 176F4601
E2 Frame 176F1852
NEMA-3R (Welded Enclosures) D3 Frame 176F0296 175R1068
D4 Frame 176F0295
E2 Frame 176F0298
Pedestal D Frames 176F1827 175R5642
Back Channel Duct Kit D3 1800mm 176F1824 175R5640
(Top & Bottom) D4 1800mm 176F1823
D3 2000mm 176F1826
D4 2000mm 176F1825
E2 2000mm 176F1850
E2 2200mm 176F0299
Back Channel Duct Kit D3/D4 Frames 176F1775 175R1107
(Top Only) E2 Frame 176F1776
IP00 Top & Bottom Covers D3/D4 Frames 176F1862 175R1106
(Welded Enclosures) E2 Frame 176F1861
IP00 Top & Bottom Covers D3 Frames 176F1781 175R0076
(Rittal Enclosures) D4 Frames 176F1782
E2 Frame 176F1783
IP00 Motor Cable Clamp D3 Frame 176F1774 175R1109
D4 Frame 176F1746
E2 Frame 176F1745
IP00 Terminal Cover D3/D4 Frame 176F1779 175R1108
Mains Shield D1/D2 Frames 176F0799 175R5923
E1 Frame 176F1851
Input Plates See Instr 175R5795
Loadshare D1/D3 Frame 176F8456 175R5637
D2/D4 Frame 176F8455
Top Entry Sub D or Shield Termination D3/D4/E2 Frames 176F1742 175R5964
4.2.3 Ordering Numbers: Harmonic Filters
Harmonic filters are used to reduce mains harmonics.
• AHF 010: 10% current distortion
• AHF 005: 5% current distortion
VLT
®
HVAC Drive Design Guide 4 How to Order
MG.11.B9.02 - VLT
®
is a registered Danfoss trademark 71
4

Danfoss VLT HVAC Specifications

General

Enclosure Rating	IP20, IP21, IP54, IP55, IP66
Storage Temperature Range	-25°C to +70°C
Output Voltage Range	0-100% of supply voltage
Communication Protocols	Modbus RTU, BACnet, Ethernet/IP, Profibus DP
Ambient Temperature Range	-10°C to +50°C (without derating)
Relative Humidity	5% to 95% non-condensing
Altitude	Up to 1000 m without derating
Cooling Method	Air cooled
Application	HVAC systems, Pumps, Fans, Compressors
Voltage Range	200-240 V, 380-500 V, 525-600 V
Frequency Range	0 Hz to 590 Hz
