Danfoss VLT HVAC

380-415 VAC, 50 Hz
I
AHF,N
[A] Typical Motor Used [kW] Danfoss ordering number
Frequency converter size
AHF 005 AHF 010
10 1.1 - 4 175G6600 175G6622 P1K1, P4K0
19 5.5 - 7.5 175G6601 175G6623 P5K5 - P7K5
26 11 175G6602 175G6624 P11K
35 15 - 18.5 175G6603 175G6625 P15K - P18K
43 22 175G6604 175G6626 P22K
72 30 - 37 175G6605 175G6627 P30K - P37K
101 45 - 55 175G6606 175G6628 P45K - P55K
144 75 175G6607 175G6629 P75K
180 90 175G6608 175G6630 P90K
217 110 175G6609 175G6631 P110
289 132 175G6610 175G6632 P132 - P160
324 160 175G6611 175G6633
370 200 175G6688 175G6691 P200
506 250
175G6609
+ 175G6610
175G6631
+ 175G6632
P250
578 315 2x 175G6610 2x 175G6632 P315
648 355 2x175G6611 2x175G6633 P355
694 400
175G6611
+ 175G6688
175G6633
+ 175G6691
P400
740 450 2x175G6688 2x175G6691 P450
380 - 415 VAC, 60 Hz
I
AHF,N
[A] Typical Motor Used [HP] Danfoss ordering number
Frequency converter size
AHF 005 AHF 010
10 1.1 - 4 130B2540 130B2541 P1K1 - P4K0
19 5.5 - 7.5 130B2460 130B2472 P5K5 - P7K5
26 11 130B2461 130B2473 P11K
35 15 - 18.5 130B2462 130B2474 P15K, P18K
43 22 130B2463 130B2475 P22K
72 30 - 37 130B2464 130B2476 P30K - P37K
101 45 - 55 130B2465 130B2477 P45K - P55K
144 75 130B2466 130B2478 P75K
180 90 130B2467 130B2479 P90K
217 110 130B2468 130B2480 P110
289 132 130B2469 130B2481 P132
324 160 130B2470 130B2482 P160
370 200 130B2471 130B2483 P200
506 250 130B2468
+ 130B2469
130B2480
+ 130B2481
P250
578 315 2x 130B2469 2x 130B2481 P315
648 355 2x130B2470 2x130B2482 P355
694 400 130B2470
+ 130B2471
130B2482
+ 130B2483
P400
740 450 2x130B2471 130B2483 P450
440-480 VAC, 60 Hz
I
AHF,N
[A] Typical Motor Used [HP] Danfoss ordering number
Frequency converter size
AHF 005 AHF 010
10 1.5 - 7.5 130B2538 130B2539 P1K1 - P5K5
19 10 - 15 175G6612 175G6634 P7K5 - P11K
26 20 175G6613 175G6635 P15K
35 25 - 30 175G6614 175G6636 P18K - P22K
43 40 175G6615 175G6637 P30K
72 50 - 60 175G6616 175G6638 P37K - P45K
101 75 175G6617 175G6639 P55K
144 100 - 125 175G6618 175G6640 P75K - P90K
180 150 175G6619 175G6641 P110
217 200 175G6620 175G6642 P132
289 250 175G6621 175G6643 P160
370 350 175G6690 175G6693 P200
434 350 2x175G6620 2x175G6642 P250
506 450 175G6620 + 175G6621 175G6642 + 175G6643 P315
578 500 2x 175G6621 2x 175G6643 P355
648 550-600 2x175G6689 2x175G6692 P400
694 600 175G6689 + 175G6690 175G6692 + 175G6693 P450
740 650 2x175G6690 2x175G6693 P500
Matching the frequency converter and filter is pre-calculated based on 400V/480V and on a typical motor load (4 pole) and 110 % torque.
