Danfoss VLT HVAC

500-525 VAC, 50 Hz
I
AHF,N
[A] Typical Motor Used [kW] Danfoss ordering number
Frequency converter size
AHF 005 AHF 010
10 1.1 - 7.5 175G6644 175G6656 P1K1 - P7K5
19 11 175G6645 175G6657 P11K
26 15 -18.5 175G6646 175G6658 P15K - P18K
35 22 175G6647 175G6659 P22K
43 30 175G6648 175G6660 P30K
72 37 -45 175G6649 175G6661 P45K - P55K
101 55 175G6650 175G6662 P75K
144 75 - 90 175G6651 175G6663 P90K - P110
180 110 175G6652 175G6664 P132
217 132 175G6653 175G6665 P160
289 160 - 200 175G6654 175G6666 P200 - P250
324 250 175G6655 175G6667 P315
397 315 175G6652 + 175G6653 175G6641 + 175G6665 P400
434 355 2x175G6653 2x175G6665 P450
506 400 175G6653 + 175G6654 175G6665 + 175G6666 P500
578 450 2X 175G6654 2X 175G6666 P560
613 500 175G6654 + 175G6655 175G6666 + 175G6667 P630
690 VAC, 50 Hz
I
AHF,N
[A] Typical Motor Used [kW] Danfoss ordering number
Frequency converter size
AHF 005 AHF 010
43 45 130B2328 130B2293
72 45 - 55 130B2330 130B2295 P37K - P45K
101 75 - 90 130B2331 130B2296 P55K - P75K
144 110 130B2333 130B2298 P90K - P110
180 132 130B2334 130B2299 P132
217 160 130B2335 130B2300 P160
288 200 - 250 2x130B2333 130B2301 P200 - P250
324 315 130B2334 + 130B2335 130B2302 P315
397 400 130B2334 + 130B2335 130B2299 + 130B2300 P400
434 450 2x130B2335 2x130B2300 P450
505 500 * 130B2300 + 130B2301 P500
576 560 * 2x130B2301 P560
612 630 * 130B2301 + 130B2300 P630
730 710 * 2x130B2302 P710
Table 4.3: * For higher currents, please contact Danfoss.
VLT
®
HVAC Drive Design Guide 4 How to Order
MG.11.B9.02 - VLT
®
is a registered Danfoss trademark 73
4
