4.2.5 Ordering Numbers: Sine-Wave Filter Modules, 525-600/690 VAC
Mains supply 3 x 525 to 690 [VAC]
Frequency converter size
Minimum switching fre-
quency [kHz]
Maximum output
frequency [Hz]
Part No. IP20 Part No. IP00
Rated filter cur-
rent at 50 Hz [A]
525-600 [VAC] -690 [VAC]
P1K1 2 100 130B2341 130B2321 13
P1K5 2 100 130B2341 130B2321 13
P2k2 2 100 130B2341 130B2321 13
P3K0 2 100 130B2341 130B2321 13
P4K0 2 100 130B2341 130B2321 13
P5K5 2 100 130B2341 130B2321 13
P7K5 2 100 130B2341 130B2321 13
P11K 2 100 130B2342 130B2322 28
P15K 2 100 130B2342 130B2322 28
P18K 2 100 130B2342 130B2322 28
P22K 2 100 130B2342 130B2322 28
P30K 2 100 130B2343 130B2323 45
P37K P45K 2 100 130B2344 130B2324 76
P45K P55K 2 100 130B2344 130B2324 76
P55K P75K 2 100 130B2345 130B2325 115
P75K P90K 2 100 130B2345 130B2325 115
P90K P110 2 100 130B2346 130B2326 165
P132 2 100 130B2346 130B2326 165
P160 2 100 130B2347 130B2327 260
P200 2 100 130B2347 130B2327 260
P250 2 100 130B2348 130B2329 303
P315 2 100 130B2370 130B2341 430
P355 1.5 100 130B2370 130B2341 430
P400 1.5 100 130B2370 130B2341 430
P450 1.5 100 130B2371 130B2342 530
P500 1.5 100 130B2371 130B2342 530
P560 1.5 100 130B2381 130B2337 660
P630 1.5 100 130B2381 130B2337 660
P710 1.5 100 130B2382 130B2338 765
P800 1.5 100 130B2383 130B2339 940
P900 1.5 100 130B2383 130B2339 940
P1M0 1.5 100 130B2384 130B2340 1320
P1M2 1.5 100 130B2384 130B2340 1320
P1M4 1.5 100 2x130B2382 2x130B2338 1479
NB!
When using Sine-wave filters, the switching frequency should comply with filter specifications in par. 14-01
Switching Frequency .
NB!
See also Output Filter Design Guide, MG.90.Nx.yy
