4.2.6 Ordering Numbers: du/dt Filters, 380-480 VAC
Mains supply 3x380 to 3x480 VAC
Frequency converter size
Minimum switching fre-
quency [kHz]
Maximum output frequen-
cy [Hz]
Part No. IP20 Part No. IP00
Rated filter current at 50
Hz [A]
380-439[VAC] 440-480 [VAC]
P11K P11K 4 100 130B2396 130B2385 24
P15K P15K 4 100 130B2397 130B2386 45
P18K P18K 4 100 130B2397 130B2386 45
P22K P22K 4 100 130B2397 130B2386 45
P30K P30K 3 100 130B2398 130B2387 75
P37K P37K 3 100 130B2398 130B2387 75
P45K P45K 3 100 130B2399 130B2388 110
P55K P55K 3 100 130B2399 130B2388 110
P75K P75K 3 100 130B2400 130B2389 182
P90K P90K 3 100 130B2400 130B2389 182
P110 P110 3 100 130B2401 130B2390 280
P132 P132 3 100 130B2401 130B2390 280
P160 P160 3 100 130B2402 130B2391 400
P200 P200 3 100 130B2402 130B2391 400
P250 P250 3 100 130B2277 130B2275 500
P315 P315 2 100 130B2278 130B2276 750
P355 P355 2 100 130B2278 130B2276 750
P400 P400 2 100 130B2278 130B2276 750
P450 2 100 130B2278 130B2276 750
P450 P500 2 100 130B2405 130B2393 910
P500 P560 2 100 130B2405 130B2393 910
P560 P630 2 100 130B2407 130B2394 1500
P630 P710 2 100 130B2407 130B2394 1500
P710 P800 2 100 130B2407 130B2394 1500
P800 P1M0 2 100 130B2407 130B2394 1500
P1M0 2 100 130B2410 130B2395 2300
NB!
See also Output Filter Design Guide, MG.90.Nx.yy
