Mechanical dimensions
Enclosure size (kW) D1 D2 D3 D4 E1 E2 F1 F2 F3 F4
380-480 VAC
525-690 VAC
110-132
45-160
160-250
200-400
110-132
45-160
160-250
200-400
315-450
450-630
315-450
450-630
500-710
710-900
800-1000
1000-1400
500-710
710-900
800-1000
1000-1400
IP
NEMA
21/54
Type 1/12
21/54
Type 1/12
00
Chassis
00
Chassis
21/54
Type 1/12
00
Chassis
21/54
Type 1/12
21/54
Type 1/12
21/54
Type 1/12
21/54
Type 1/12
Shipping dimensions (mm):
Width 1730 1730 1220 1490 2197 1705 2324 2324 2324 2324
Height 650 650 650 650 840 831 1569 1962 2159 2559
Depth 570 570 570 570 736 736 927 927 927 927
FCDrive dimensions: (mm)
Height
Back plate A 1209 1589 1046 1327 2000 1547 2281 2281 2281 2281
Width
Back plate
B 420 420 408 408 600 585 1400 1800 2000 2400
Depth
C 380 380 375 375 494 494 607 607 607 607
Dimensions brackets (mm/inch)
Centre hole to edge
a 22/0.9 22/0.9 22/0.9 22/0.9 56/2.2 23/0.9
Centre hole to edge b 25/1.0 25/1.0 25/1.0 25/1.0 25/1.0 25/1.0
Hole diameter c 25/1.0 25/1.0 25/1.0 25/1.0 25/1.0 25/1.0
d 20/0.8 20/0.8 20/0.8 20/0.8 27/1.1
e 11/0.4 11/0.4 11/0.4 11/0.4 13/0.5
f 22/0.9 22/0.9 22/0.9 22/0.9
g 10/0.4 10/0.4 10/0.4 10/0.4
h 51/2.0 51/2.0 51/2.0 51/2.0
i 25/1.0 25/1.0 25/1.0 25/1.0
j 49/1.9 49/1.9 49/1.9 49/1.9
Hole diameter k 11/0.4 11/0.4 11/0.4 11/0.4
Max weight
(kg)
104 151 91 138 313 277 1004 1246 1299 1541
Please contact Danfoss for more detailed information and CAD drawings for your own planning purposes.
VLT
®
HVAC Drive Design Guide 5 How to Install
MG.11.B9.02 - VLT
®
is a registered Danfoss trademark
83
