DK-45 Kullanım Kılavuzu V1.0 (22.09.2016)
- 55 -
CONTROLLER REGISTERS
ADDR.
NAME
DESCRIPTION
LENGTH
READ/
WRITE
DATA TYPE
COEFF
40033
Motor status
Current status of the motor
0: Compressor STOP mode
1: Motor in star run
2: Motor in delta (off_load)
3: Motor in delta (on_load)
4: Unload timer
5: Motor stopped,
compressor in RUN mode
16 BIT
R-O
unsigned word
1
40034
Last fault code
Currently active alarm,
warning or service request
code.
Fault code list is given in
chapter 5.
16 BIT
R-O
unsigned word
1
40035
Relay outputs
Current status of relays:
bit 1-3:-
bit 4: RL1
bit 5: RL5
bit 6: RL4
bit 7: RL2
bit 8: RL3
bit 9-16: -
16 BIT
R-O
unsigned word
1
40036
-
-
16 BIT
R-O
unsigned word
1
40037
Alarm 1
Alarm #1 in alarm history
16 BIT
R-O
unsigned word
1
40038
Alarm 2
Alarm #2 in alarm history
16 BIT
R-O
unsigned word
1
40039
Alarm 3
Alarm #3 in alarm history
16 BIT
R-O
unsigned word
1
40040
Alarm 4
Alarm #4 in alarm history
16 BIT
R-O
unsigned word
1
40041
Alarm 5
Alarm #5 in alarm history
16 BIT
R-O
unsigned word
1
40042
Alarm 6
Alarm #6 in alarm history
16 BIT
R-O
unsigned word
1
40043
Alarm 7
Alarm #7 in alarm history
16 BIT
R-O
unsigned word
1
40044
Alarm 8
Alarm #8 in alarm history
16 BIT
R-O
unsigned word
1
40045
Alarm 9
Alarm #9 in alarm history
16 BIT
R-O
unsigned word
1
40046
Utility mains topology
1:one phase 2:two phases
3: three phase
16 BIT
R-O
unsigned word
1
40047
0-10 V output
Output analog value
(0-1023)
16 BIT
R-O
unsigned word
1
40048
-
16 BIT
R-O
unsigned word
1
40049
-
16 BIT
R-O
unsigned word
1
40050
-
16 BIT
R-O
unsigned word
1
40051
-
16 BIT
R-O
unsigned word
1
40052
-
16 BIT
R-O
unsigned word
1
40053
-
16 BIT
R-O
unsigned word
1
40054
LEDs
LED statuses
16 BIT
R-O
unsigned word
1
40055
% Load
Load percentage
16 BIT
R-O
unsigned word
1
40056
Master address
Modbus address of master
16 BIT
R-O
unsigned word
1
40057
Number of controllers
Number of controllers in
multi compressor
16 BIT
R-O
unsigned word
1
40058
Requests
Start Stop request
16 BIT
R-O
unsigned word
1
