DK-45 Kullanım Kılavuzu V1.0 (22.09.2016)
- 56 -
CONTROLLER REGISTERS
ADDR.
NAME
DESCRIPTION
LENGTH
READ/
WRITE
DATA TYPE
COEFF
40059
Flashing counter
Flashing relay counter value
32 BIT
R-O
unsigned dword
2
40060
40061
Active flashing relays
Number of active flashing
relays
16 BIT
R-O
unsigned word
1
40062
Flashing number
Total number of flashing
relays
16 BIT
R-O
unsigned word
1
40063
Firmware version
Controller software version
16 BIT
R-O
unsigned word
1
40064
-
40128
reserved
-
16 BIT
R-O
unsigned word
1
PROGRAM PARAMETERS
ADDR.
NAME
DESCRIPTION
LENGTH
READ/
WRITE
DATA TYPE
COEFF
.
40129
E.01
Explained in chapter 10.2
16 BIT
R/W
unsigned word
1
40130
E.02
Explained in chapter 10.2
16 BIT
R/W
unsigned word
0.1
40131
E.03
Explained in chapter 10.2
16 BIT
R/W
unsigned word
0.1
40132
E.04
Explained in chapter 10.2
16 BIT
R/W
unsigned word
0.1
40133
E.05
Explained in chapter 10.2
16 BIT
R/W
unsigned word
0.1
40134
E.06
Explained in chapter 10.2
16 BIT
R/W
signed word
0.1
40135
E.07
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40136
E.08
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40137
E.09
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40138
E.10
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40139
E.11
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40140
E.12
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40141
E.13
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40142
E.14
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40143
E.15
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40144
C.01
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40145
E.16
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40146
E.17
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40147
E.18
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40148
E.19
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40149
E.20
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40150
E.21
Explained in chapter 10.2
16 BIT
R/W
signed word
1
40151
E.22
Explained in chapter 10.2
16 BIT
R/W
unsigned word
1
40152
E.23
Explained in chapter 10.2
16 BIT
R/W
unsigned word
1
40153
E.24
Explained in chapter 10.2
16 BIT
R/W
unsigned word
1
40154
E.25
Explained in chapter 10.2
16 BIT
R/W
unsigned word
1
