ENTER/EXIT PROGRAMMING MODE 1D SYMBOLOGIES

154

CODISCAN™ HS7600

FOLLETT 2 OF 5

The following options apply to the Follett 2 of 5 symbology.

Follett 2 of 5 Enable/Disable

Enables/Disables ability of reader to decode Follett 2 of 5 labels.

$CF2EN00



Follett 2 of 5 = Disable

Follett 2 of 5 = Enable

$CF2EN01
