CODISCAN™ HS7600 TECHNICAL SPECIFICATIONS
PRODUCT REFERENCE GUIDE 267
Skew Tolerance
a
+/- 60°
Pitch Tolerance
a
+/- 60°
Roll Tolerance
a
+/- 180°
Ambient Light Up to 0 - 100,000 lux
Aimer 650 nm, 1 mW
a. Based on ISO 15423 specifications
ENVIRONMENTAL CHARACTERISTICS
Operating
Temperature
-20 to 50 °C / -4 to 122 °F
Charging
Temperature
0 to 40 °C / 32 to 104 °F
Storage
Temperature
-20 to 60 °C / -4 to 140 °F
Humidity 0 - 95% non condensing
Drop Resistance
Resists multiple drops from 1.8 m / 5.9 ft onto concrete
- IEC 60068-2-31:2008 – 1
ESD Protection 16 KV
Tumbles 1,000 at 0.5 m / 1.6 ft - IEC 60068-2-31:2008 – 2
Impact Resistance >IK06(1J) - IEC60068-2-75
Particulate and Water
Sealing
IP54 - EN 60529
FEEDBACK
Green Spot Datalogic ‘Green Spot’ on the Code for Good Read
LEDs
3 LEDs: 2 Lateral blades, rear LED spot with separate
on/off – good read, battery status, Bluetooth pairing
Audio 85 dbA – adjustable
Haptic Vibration feedback option available
RADIO CHARACTERISTICS
Bluetooth Wireless Technology
BT BLE/CLASSIC 5.2 class 1,2,3
Supports Bluetooth Low Energy 4.0, 4.1, 4.2, 5.0,
5.1, 5.2
Transmission Range
100 m / 328 ft to host (depending on Host, OK
Gateway)
Max number of devices per gateway 7
Wi-Fi (via Gateway)
• IEEE 802.11b/g/n, 1×1, 20 MHz channel band-
width, 2.4 GHz
• Wi-Fi security: WPA2/WPA3 Personal; WPA2
Enterprise PEAP, TLS, TTLS
• MQTT client protocol v. 3.1, v. 3.1.1
• WebSocket client
