Plessey ENTER/EXIT PROGRAMMING MODE

198

Gryphon™ I GFS4170/GFS4150-9

PLESSEY

The following options apply to the Plessey symbology.

Plessey Enable/Disable

Enables/Disables ability of reader to decode Plessey labels.

DEFAULT

Plessey = Disable

Plessey = Enable
