Datalogic Magellan 2300HS

108 Magellan
®
2200VS/2200VS and 2300HS/2300HS
Figure 5-2. Label ID Position Options
Label ID Control — continued
Remember to cover any unused bar codes on this and the facing page to
ensure that the scanner reads only the bar code you intend to scan.
LABEL ID TRANSMISSION: DISABLE
LABEL ID TRANSMISSION: BEFORE BAR CODE DATA
OR
Prefix Suffix
SCANNER
Label ID Label IDBar Code DataAim ID
