Product Reference Guide 403
• Prefix must be ASCII characters ']E0'- total length including prefix
must be 16.
• Example: ']E01101234567891'.
EAN-8
• Check digit must be included in label data and is assumed to be cor-
rect.
• Prefix must be ASCII characters ']E4' - total length including prefix
must be 11.
• Example: ']E400210126'.
2-Digit Supplemental
• Supplemental data is appended to any EAN base label.
• Prefix must be ASCII characters ']E1'.
• length of Supplemental data including prefix must be 5. Total
required length is 21 for EAN-13 and 16 for EAN-8.
• Prefix for the main body portion of the label for UPCA/UPCE/
EAN13 can be ]E0 or ]E3.
• If the main body prefix for UPCA/UPCE/EAN13 is ]E0, then the
2-digit addon portion of the label must have a prefix of ]E1.
Examples: addon portion is highlighted data is underlined.
UPC-A 2-Digit addon ']E00060992011187]E112'
UPC-E 2-Digit addon ']E00000000998875]E112
'
EAN-8 2-Digit addon ']E400210126]E112
'
EAN-13 2-Digit addon ']E01101234567891]E112
'
UPC-A ]E3006099201118712
UPC-E ]E3000000099887512
EAN-13 ]E3110123456789112

Datalogic Magellan 2300HS Specifications

General

Scanner type	1D
Decoding standards	GS1 DataBar
Input voltage	90 - 265 V
Power requirements	47-63 Hz
Power consumption (standby)	2.5 W
Dimensions (WxDxH)	152 x 152 x 86 mm
Certification	RoHS
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
