Interface Related Features
Interface Type
Specifies the current scanner interface. Selections are:
INTERFACE (I/F) TYPE I/F I.D. NUMBER INTERFACE (I/F) TYPE
I/F I.D. NUMBER
RS-232 Standard 05 Keyboard Wedge A 25
RS-232 Wincor-Nixdorf 12 Keyboard Wedge B 26
RS-232 Single Cable 20 Keyboard Wedge C 27
USB-OEM 45 Keyboard Wedge D 28
IBM
Port 17
04 Keyboard Wedge E 29
IBM
Port 5B
08 Keyboard Wedge F 2A
IBM
Port 9B
23 Keyboard Wedge G 31
USB Keyboard 35 Keyboard Wedge H 32
Keyboard Wedge I 33
NOT USER-SELECTABLE Keyboard Wedge J 34
Null Interface

Datalogic Magellan 2300HS Specifications

General

Scanner type	1D
Decoding standards	GS1 DataBar
Input voltage	90 - 265 V
Power requirements	47-63 Hz
Power consumption (standby)	2.5 W
Dimensions (WxDxH)	152 x 152 x 86 mm
Certification	RoHS
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
