Product Reference Guide 381
Appendix B
Cable Information
Introduction
The following pages contain pinout information, enabling you to create
an auxilary port cable for use in interconnecting the scanner to an external
handheld scanner.
General Specifications
Wire Requirements
Cable length should not exceed 15 feet.
Wire gauge = Standard for RJ-45 connectors (28-26 AWG).
If run exceeds 15 feet, we recommend 26 AWG wire size.
