Datalogic Magellan 2300HS User Manual

370 Magellan
®
2200VS/2200VS and 2300HS/2300HS
MSI/Plessey Length 1
Length 1 is the minimum label length if in variable length mode, or the
first fixed length if in fixed length mode (see
MSI/Plessey Length Con-
trol)
. Length includes the barcode’s check and data characters.
To set this feature:
1. Scan the SWITCH bar code.
2. Scan the bar code,
SET MSI/PLESSEY LENGTH 1 below. You’ll
need to cover any unused bar codes on this and the facing page to
ensure that the scanner reads only the bar code you intend to scan.
3. Scan the appropriate digits from the keypad in
Appendix C that rep-
resent the desired label length. The selectable range for this option is
04 to 16. Pad all single digit numbers with a leading zero to yield a
two-digit entry (04-16).
4. Complete the programming sequence by scanning the SWITCH
bar code.
SET MSI/PLESSEY LENGTH 1

Datalogic Magellan 2300HS Specifications

General

Scanner type	1D
Decoding standards	GS1 DataBar
Input voltage	90 - 265 V
Power requirements	47-63 Hz
Power consumption (standby)	2.5 W
Dimensions (WxDxH)	152 x 152 x 86 mm
Certification	RoHS
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
