Product Reference Guide 409
Appendix F
Keyboard Function Key
Mappings
Keyboard Model Cross Reference
Tabl e F- 41 0 summarizes the keyboard models, their defined protocol, scancode set, and some
unique features. The remaining tables in this chapter provide the function key maps associated
with each of the scancode sets.

Datalogic Magellan 2300HS Specifications

General

Scanner type	1D
Decoding standards	GS1 DataBar
Input voltage	90 - 265 V
Power requirements	47-63 Hz
Power consumption (standby)	2.5 W
Dimensions (WxDxH)	152 x 152 x 86 mm
Certification	RoHS
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
