2200VS/2200VS and 2300HS/2300HS
5-Digit Supplemental
• Supplemental data is appended to any EAN base label.
• Prefix must be ASCII characters ']E2'.
• Length of supplemental data including prefix must be 8. Total
required length is 24 for EAN-13 and 19 for EAN-8.
• Prefix for the main body portion of the label for UPCA/UPCE/
EAN13 can be ]E0 or ]E3.
• If the main body prefix for UPCA/UPCE/EAN13 is ]E0, then the
5-digit addon portion of the label must have a prefix of ]E2.
Examples: addon portion is highlighted data is underlined.
UPC-A 5-Digit addon ']E00060992011187]E212345'
UPC-E 5-Digit addon ']E00000000998875]E212345
'
EAN-8 5-Digit addon ']E400210126]E212345
'
EAN-13 5-Digit addon ']E01101234567891]E212345
'
UPC-A ]E3006099201118712345
UPC-E ]E3000000099887512345
EAN-13 ]E3110123456789112345
