Datalogic Magellan 2300HS User Manual

84 Magellan
®
2200VS/2200VS and 2300HS/2300HS
Interface Type — continued
4. Complete the programming sequence by scanning the SWITCH
bar code.
5. Connect new interface cable(s).
NOTE
Once the correct interface has been set, it will be necessary to pro-
ceed to the appropriate pages in this manual that select parameters
and options for that interface. For example, if RS-232 is selected, turn
to the pages in this manual headed as features specific to the RS-232
interface.

Datalogic Magellan 2300HS Specifications

General

Scanner type	1D
Decoding standards	GS1 DataBar
Input voltage	90 - 265 V
Power requirements	47-63 Hz
Power consumption (standby)	2.5 W
Dimensions (WxDxH)	152 x 152 x 86 mm
Certification	RoHS
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
