Datalogic PowerScan M8300 User Manual

Enter Configuration
Exit and Save Configuration
Ì$+;Î
CODE SELECTION
Ì$-?Î
97
SELECT EAN/UPC PREFIXES
When scanning the following codes, barcodes starting with the selected
prefixes will be read and transmitted only if the ADD ON is present
NOTE
. If no ADD
ON is found, the barcode will not be read. Barcodes starting with different
characters are read regardless of ADD ON presence and transmitted always
without ADD ON.

ÌET0wÎ
Cancel All Selections
OR
select one or more of the following prefixes:
ÌET1378ET2379PÎ
378/379
434/439
ÌET3434ET4439ÉÎ
ÌET5414ET6419}Î
414/419
977
ÌET7977QÎ
ÌET8978ZÎ
978
979
ÌET9979cÎ
The commands above are not mutually exclusive. They can be used to configure more than one
set of prefixes simultaneously.

Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
