Datalogic PowerScan M8300 User Manual

POWERSCAN
®
D8330/M8300/M8300-DK
198
6.3 MESSAGES FROM HOST TO READER
The general format to enable the Scanner for a 2 way communication is:
[Scanner_Addr] [Scanner_Addr_delimiter]
MESSAGE
[CR]
NOTE:
• If you have enabled the Scanner Address Stamping or the Scanner Address
Delimiter, you must specify them in every message.
The format for other asynchronous messages is:
[Scanner_Addr] [Scanner_Addr_delimiter] [DC2]
MESSAGE
[CR]
where DC2 is ASCII 0x12 (^R) character.
• If you have not enabled the Scanner Address Stamping or the Scanner Address
Delimiter, you must not specify them. In this case all messages will be implicitly
addressed to the 'binded' Scanner of the cradle directly connected to the serial
line.
• The Scanner can only receive messages if two-way mode is enabled. (See par.
5.9.4, “Transmission Mode”, the command is on page 180).
• Messages cannot start with '$+' because they would be interpreted as a
configuration command.
• You can send a message to the Scanner only while it is on. This happens when
it has sent a message to the host and the radio timeout has not yet expired. (See
par. 5.9.1, "Radio Protocol Timeout"; command is on page 130).
• If you want to control the Scanner's beeper from the host, you will also probably
want to disable the good transmission beep that is emitted when the code is
received from the cradle. (See command on page 86).
The message field can store plain text and escape sequences.
• Escape sequences are interpreted as commands.
• Plain text is directly printed on the display. If writing beyond the end of line, the
display does not wrap automatically. Extra characters are ignored. Control
characters are not interpreted (i.e. LF, FF, etc.).

Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
