2.10 MOUNTING THE BC-80X0 / C-8000 CRADLE
The cradle package contains the following items:
BC-80X0 / C-8000 Cradle
BC-80X0 Quick Reference / C-8000 Quick Reference
BC-8000 Antenna
2 wall-mounting lock hinges
2 adhesive strips
4 rubber feet
1 horizontal base
1 inclined base
The cradle (either BC-80X0 or C-8000) can be mounted for portable or fixed desktop
usage, or it can be fixed to a wall. The horizontal base allows portable and fixed
desktop usage, while the inclined base provides desktop and wall mounting
guaranteeing a comfortable handling of the PowerScan
®
M8300 reader.
BC-80X0/C-8000 Cradle mounted on the Horizontal Base
BC-80X0/C-8000 Cradle mounted on the Inclined Base
