POWERSCAN® D8330/M8300/M8300-DK
192
5.16 FIRMWARE UPGRADE
Device firmware upgrades can be performed from your PC through either a USB or
serial connection (RS-232). Download the free configuration software tool Aladdin
from the Datalogic web site:
http://www.scanning.datalogic.com and install it by
clicking on the setup file.
Procedure

:
Connect the device to the PC via USB or serial connection (RS-232).

Launch Aladdin on your PC. From the menu, select Tools > firmware upgrade.

Read the code below and position the reader onto the cradle:
prepare device for firmware upgrade
Ì$+RN2$-SÎ
OR
Press the cradle button if present (to update the cradle only).
The device will automatically be reset.

Proceed with the firmware upgrade (see the Aladdin on-line help for details).
Do not interrupt firmware upgrade downloading for any reason.
CAUTION

Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
