Datalogic PowerScan M8300 User Manual

POWERSCAN
®
D8330/M8300/M8300-DK
204
7.2 POWERSCAN
®
M8300
Electrical and General Features
Battery Type 2150 Li-Ion battery pack
Recharge Time
max. 4 hours with external power supply
max 10 hours with Host power
Operating autonomy
(continuous reading)
60,000 reads (typical)
Display
(Only available with some models)
LCD 4 lines x 16 chars
Programmable font and backlight
Indicators
Good Read LED (green)
Good Read Spot (green), Beeper
Laser Features
M8300 M8300 AR
Light Source VLD between 630~680 nm
Scan Rate 35 ± 5 scans/sec
Power (max) in mW 0.9 mW 1.3 mW
Scan Angle 42°
13.5° ± 0.7
PCS minimum
(Datalogic Test Chart)
15% 25%
Maximum Resolution 0.076 mm (3 mils) 0.19 mm (7.5 mils)
Reading Field Width see reading diagrams (par. 7.7)
Laser Safety Class CLASS 2 EN 60825-1 / CDRH
Environmental Features
Working Temperature -20° to +50 °C / -4° to +122 °F
Storage Temperature -20° to +70 °C / -4° to +158 °F
Humidity 90% non condensing
Drop resistance
(on concrete)
IEC 68-2-32 Test ED
2 m
Protection Class IP65 (IP64 for models with display)
Mechanical Features
Weight (with batteries) about 400 g (14.10 oz)
Dimensions 212 x 109 x 71 mm (8.34 x 4.49 x 2.79 in)
Material Polycarbonate molded with rubber

Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
