MESSAGE FORMATTING
195
6 MESSAGE FORMATTING
6.1 STANDARD MESSAGE FORMATTING
The system always provides scanner to host data communication using the following
message formatting:
Output Message from
PowerScan
®
D8330 or standard PowerScan
®
M8300 Stand-
alone
[Header] [Scanner_Addr] [Scanner_Addr_delimiter] ] [Cradle_Addr] [Cradle_Addr_delimiter]
[Time stamp] [Ts_delimiter] [Code ID] [Code Length]
CODE
[Terminator]
Towards Host
[Items in square brackets are optional.]
Output Message from PowerScan
®
M8300 STAR-System™
[Time stamp]
[Ts_delimiter] [Header] [Code ID] [Code Length]
CODE
[Terminator]
Towards Host
[Items in square brackets are optional.]
For PowerScan
®
M8300 models with display, if the RS-232 interface is selected for
communication between the Host and the BC-80X0 cradle, then the following
additional communications between
Host and Scanner
can occur:
• The Host can send messages to any scanner associated with that cradle to
control the Scanner’s display, LEDs and beeper.
• The Scanner can send up to 3 user-defined characters to the Host using the 3
command keys on the Scanner.

Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
