POWERSCAN® D8330/M8300/M8300-DK
182
5.9.6 Single Store
When single store mode is enabled, if the PowerScan
®
M8300 fails to transmit a
code to the cradle, it enters a special operating mode that prevents the user from
reading barcodes. When such operating mode is entered, the trigger no longer
enables barcode reading but is used to retry transmission itself for the number of
attempts selected in configuration. Once the transmission is successful the reader
returns to the standard mode. If transmission is not successful after the number of
configured attempts, the code is discarded.
Single store may be useful if you often read codes at the limit of the coverage area
and there is a chance that code transmission can fail. In such case single store
allows you to move to a more favorable position or location (i.e. closer to the cradle)
and retry transmission without the necessity of re-reading the code since it is already
stored in the reader.
Conversely, if single store is disabled, and the user wants to retry transmission, the
code must be read again, and therefore the attempt must be made from basically the
same location. If the user gives up, he does not know if the transaction was
successful. (Actually the transmission could have been successful but the cradle may
have been unable to acknowledge the message). There are applications in which
there is no risk of transmission failure. In such cases it may be better to disable
single store so that the user perceives a more consistent behavior of the trigger in
that it always corresponds to code reading.
5.9.7 Batch Mode
This Operating Mode allows storing read codes in the internal reader memory. The
stored codes are transmitted to the base station at a later time according to the type
of batch mode selected.
Batch mode can be enabled either manually (normal batch mode) or automatically.
Normal batch mode temporarily suspends radio communication between reader and
base station allowing codes to be stored in the reader on a FIFO (first in, first out)
basis. This can be useful, for example, if codes must be read from a location where
there is no radio network. Upon returning to the system working area, this mode
requires reading the Start Normal Batch Transmission barcode to successively
transmit the list of stored codes to the base station. The FIFO management assures
that the first code read will be the first code to be transmitted to the base station.
The Delete Batch Data barcode allows canceling all barcode data stored in the
reader.
Automatic batch mode allows codes to be stored in the reader on a FIFO basis
whenever the reader is out of radio range. In this case radio communication is not
suspended and transmission is attempted after each code read. If transmission
cannot be successfully completed, then the code is added to the list. When the

Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
