Datalogic PowerScan M8300 User Manual

CONFIGURATION
25
4.1.4 Sending Configuration Strings from Host
An alternative configuration method is provided in Appendix A using the RS-232
interface. This method is particularly useful when many devices need to be
configured with the same settings. Batch files containing the desired parameter
settings can be prepared to configure devices quickly and easily.
4.2 SETUP PROCEDURES
For PowerScan
®
D8330 Series readers, follow the setup procedures in pars. 4.3, and
4.8.
For PowerScan
®
M8300 Series readers, the setup procedures depend on two basic
applications, Stand-alone or STAR-System™.
Stand-alone applications allow communication with the Host by either the BC-80X0
cradle (par. 4.5), or by the STAR-Modem™ radio modem (par. 4.5.2).
STAR-System™ applications allow communication with the Host through an
RS-485 network by the STARGATE™ RF base station or by the BC-8000 cradle
(par. 4.6 and par. 4.7).
Proceed as shown in the following diagram:
Begin Setup
by choosing the setup
procedure for your PowerScan
®
reader as in
dicated below.
End of Setup
Your reader is now ready to read
barcodes using the default settings.
Stand Alone Applications
PowerScan
®
M8300/BC-80X0
Par. 4.4
Par. 4.7
Optional Par. 4.4.1
multiple readers per BC-8000
PowerScan
®
M8300/STAR-Modem™
in Stand Alone Mode
Par. 4.4.2
PowerScan
®
D8330
Par. 4.3
Par. 4.7
STAR-System™ Network Applications
BC-8000
Par. 4.6
STAR-System™ Applications
PowerScan
®
M8300/STAR-System™
Par. 4.5
• STARGATE™
• BC-8000 Network
• STAR-Modem™ in STAR-System™ Mode

Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
