Datalogic PowerScan M8300 User Manual

REFERENCES
187
5.12 CUSTOM DEFAULT CONFIGURATION
Read the following code to set the reader
user-defined configuration
as custom
default configuration:
Save User-defined Configuration as Custom Default
Ì$+$0ÂÎ
Read the following code whenever you need to restore the custom default
configuration:
Restore Custom Default Configuration
Ì$+$1$Î
5.13 CODE TYPE RECOGNITION
This procedure allows the reader to enter a particular state during which it reads and
transmits to the Host information about the family type of codes unknown to the user
(with the exception of MSI, Code 49 and Code 16k code types). It is also possible to
read and transmit configuration strings without interpreting them.
All codes are read ignoring the check digit.
Follow the given procedure:
 Read the following code to enter the code type recognition mode:
code type recognition
Ì#+CODEÂÎ
 Read existing codes whose family type you need to check.
 Read the following code to return to the reader's normal functioning:
exit code type recognition mode
Ì$-?Î


Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
