Datalogic PowerScan M8300 User Manual

Enter Configuration
Exit and Save Configuration
Ì$+;Î
RADIO PARAMETERS
Ì$-?Î
134
BATCH MODE
 disable batch
ÌBZ0ÄÎ
enable automatic batch
enable normal batch
ÌBZ1ÇÎ
ÌBZ2ÊÎ
See par. 5.9.7 for details.
The following batch management parameters are complete commands and do not
require reading the Enter and Exit configuration codes.
start normal batch transmission
Ì#+BFlush]Î
#+BFlush
delete batch data
Ì#+BReset\Î
#+BReset
FIND ME
disable
ÌBk0;Î
 enable
ÌBk1>Î
See par. 5.9.8 for details.

Datalogic PowerScan M8300 Specifications

General

Scanner type	1D
Maximum range	30 m
Read rate (max)	40 reads/s
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Code 16K, Code 49, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional
Tilt reading angle	-20 - 20 °
Pitch reading angle	-55 - 55 °
Operating time	240 min
Dimensions (WxDxH)	114 x 69 x 210 mm
Bluetooth	No
Operating frequency	910 MHz
Input voltage	10 - 30 V
Battery capacity	2150 mAh
Power requirements	0.33 - 1A
Number of reads per charge	60000
Certification	IP64, China RoHS, EU RoHS, CDRH Class II, IEC 60825-1 Class 2
Keys quantity	3 keys
Product color	Black, Yellow
LED indicators	Charging, Power
Display resolution	32 x 96 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	393 g
